VMC-1300HD
The Gate – Eclipse Heavy Duty VMC range covers 2 models ranging from 1000×500×570mm to 1300×650×710mm working envelopes, and table load ranging from 800 to 1000Kg. Ideal for larger, heavy duty machining. All Gate machines are supplied with a 2 year warranty as standard.
If you are interested in this product please CONTACT US
| MODEL | VMC-1300HD |
|---|---|
| Table size | 1500 × 600mm |
| T-slot (W/pitch/No.) | 18/5/110mm |
| Table loading capacity | 1000Kg |
| Travel X/Y/Z | 1300 × 650 × 710mm |
| Spindle nose to table | 80-790mm |
| Spindle taper | ISO-40 |
| Spindle diameter | 70mm |
| Spindle speed | 10000rpm |
| Motor output | 11/15KW |
| XYZ ball screws (dia. × pitch/class) | 40mm × 12/C3 |
| Transmission type | Direct |
| XYZ rapid traverse | 24m/min |
| XYZ feed rate | 8m/min |
| Tool shank type | BT/CAT #40 |
| No. of tools | 24 |
| ATC type | Arm |
| Tool changing time T/T | 4 seconds |
| Max. tool diameter | 80.7mm |
| Max. tool length | 300mm |
| Max. tool weight | 8Kg |
| Positioning accuracy mm/dist. | ±0.005/300 |
| Repeatability | 0.005mm |
| Weight | 7000Kg |
| Dimensions | 3.5 × 1.5 × 2.6m |
